To select the size of an evaporative cooler you have to consider the airflow and the size of the area you have in mind to cool. When it comes to choosing a portable air conditioner one of the most important factors to take into account is the model s btu rating. The potential of evaporative cooling adiabatic cooling when 2 2 lbs 1kg of moisture is delivered to the air by an adiabatic humidifier 680w of evaporative cooling is achieved.
